Waste Polyester Tire Cord Fabric for Fishing Net
Tire cord fabric is very low weft density of the fabric,look like curtain,the warp bears load ,weft hold the warp.Nomally it can be used in tire cord,air spring, rubber products,helping with the great shock load and strong vibration.420D Tire cord is the star product in our company,which is frequently used in mountain bike tires.
| Quantity: | |
|---|---|
-
kindom
| Dipped N6 Tyre cord fabric | ||||||
| SPEC | UNIT | 840D/2 | 1260D/2 | 1260D/3 | 1680D/2 | 1890D/2 |
| ≥Breaking strength | N/end | 137.2 | 215.6 | 313.6 | 297.3 | 313.6 |
| 100N extension under given load | % | 9.5±0.5 | 9.5±0.5 | |||
| 88.2N extension under given load | % | 9.5±0.5 | ||||
| 66.6N extension under given load | % | 9.5±0.5 | ||||
| 44.1N extension under given load | % | 9.5±0.5 | ||||
| Adhesion | N/cm | 117.6 | 147 | 176.4 | 166.6 | 176.4 |
| Dip pick up | % | 4.5±1.0 | 4.5±1.0 | 4.5±1.0 | 4.5±1.0 | 4.5±1.0 |
| ≤ Breaking strength difference | % | 3.8 | 3.8 | 3.8 | 3.8 | 3.8 |
| ≤ shrinkage in hot air | % | 6 | 6 | 6 | 6 | 6 |
| Twist | T/m | 460±15 | 370±15 | 320±15 | 330±15 | 320±15 |
| Water content | % | 1 | 1 | 1 | 1 | 1 |
| Dipped N6 Tyre cord fabric | ||||||
| SPEC | UNIT | 840D/2 | 1260D/2 | 1260D/3 | 1680D/2 | 1890D/2 |
| ≥Breaking strength | N/end | 137.2 | 215.6 | 313.6 | 297.3 | 313.6 |
| 100N extension under given load | % | 9.5±0.5 | 9.5±0.5 | |||
| 88.2N extension under given load | % | 9.5±0.5 | ||||
| 66.6N extension under given load | % | 9.5±0.5 | ||||
| 44.1N extension under given load | % | 9.5±0.5 | ||||
| Adhesion | N/cm | 117.6 | 147 | 176.4 | 166.6 | 176.4 |
| Dip pick up | % | 4.5±1.0 | 4.5±1.0 | 4.5±1.0 | 4.5±1.0 | 4.5±1.0 |
| ≤ Breaking strength difference | % | 3.8 | 3.8 | 3.8 | 3.8 | 3.8 |
| ≤ shrinkage in hot air | % | 6 | 6 | 6 | 6 | 6 |
| Twist | T/m | 460±15 | 370±15 | 320±15 | 330±15 | 320±15 |
| Water content | % | 1 | 1 | 1 | 1 | 1 |
