Grade B nylon 6 dipped heat resistant tyre cord fabrics

Tire cord fabric is very low weft density of the fabric,looking like curtain,the waro bears load,weft hold th warp.Nomally it can be used in tire cord,air spring,rubber products,helping with the great shock load and strong vibratiom.

420D tire cord is the star product ompur copany.

Color:	black brown
Availability:

Quantity:



Inquire Add to Basket

Brand:
kingdom

Product Description

Dipped N66 tyre cord fabric
SPEC	Unit	930dtex/2	1400dtex/2	1870dtex/2	2100dtex/2
Breaking strength	N/end	≥137.2	≥211.7	≥280.0	≥310.0
Elongation at 100N(10.2kg)	%				9.0±1.0
Elongation at 88.2N(9kg)	%			8.7±1.0
Elongation at 66.6N(6.8kg)	%		8.5±1.0
Elongation at 44.1N(4.5kg)	%	8.5±1.0
Elongation at 22.3N(2.3kg)	%
Adhesion	N/cm	≥107.8	≥137.2	≥156.8	≥166.8
Cord gauge	mm	0.53±0.05	0.65±0.05	0.74±0.05	0.78±0.06
Twist	T/m	46.0±2.0	37.0±2.0	32.0±2.0	32.0±2.0
Dip pick up	%	5.0±1.0	5.0±1.0	5.0±1.0	4.5±1.0
Elongation at break	%	20±2	21±2	22±2	22±2
Moisture shrinkage	%	≤1.0	≤1.0	≤1.0	≤1.0
Heat shrinkage 150℃/2min*0.05cn/dtex	%	≤4.0	≤4.0	≤4.0	≤4.0
