Hot Sale High Strength CR 3*3 Dipped Stiff Cord for V Belt
| Color: | |
|---|---|
| Quantity: | |
-
kindom
| HMLS Polyester Dipped Stiff Cord | ||||||||||
| Test Item | Unit | 1000D/2*3 | 1500D/3*3 | 1000D/2*5 | 1000D/4*3 | 1000D/5*3 | 1000D/6*3 | 1000D/8*3 | 1000D/9*3 | 2000D/12*3 |
| Breaking Strength | N | ≥420 | ≥630 | ≥680 | ≥850 | ≥1020 | ≥1200 | ≥1680 | ≥1860 | ≥2400 |
| Elongation at Break | % | 9.5±1.5 | 9.5±1.5 | 9.5±1.5 | 9.5±1.5 | 9.5±1.5 | 10±1.5 | 10±2.0 | 10±2.0 | 10±2.0 |
| Elongation at Setload | % | 3.1±0.5 | 2.0±0.5 | 2.2±0.5 | 2.4±0.6 | 2.0±0.6 | 2.2±0.6 | 2.4±0.6 | 2.3±0.6 | 2.0±0.6 |
| @200N | @200N | @200N | @300N | @300N | @400N | @500N | @500N | @500N | ||
| Weight per 100 m | g/100m | 73±3 | 110±4 | 121±4 | 145±5 | 185±6 | 217±7 | 287±10 | 327±15 | 436±15 |
| Cord Diameter | mm | 0.9±0.1 | 1.2±0.1 | 1.24±0.1 | 1.36±0.1 | 1.55±0.1 | 1.65±0.1 | 1.95±0.15 | 2.1±0.15 | 2.4±0.15 |
| Hot air Shrinkage 150℃ 3min 130g | % | ≤3 | ≤3 | ≤3 | ≤2.8 | ≤2.8 | ≤2.6 | ≤2.8 | ≤2.8 | ≤2.8 |
| T-Adhesion at150℃30min | N/cm | ≥240 | ≥260 | ≥280 | ≥300 | ≥320 | ≥350 | ≥400 | ≥420 | ≥480 |
| High Tenacity Polyester Dipped Stiff cord | |||||||||
| Test Item | 1000D/1*3 | 1000D/2*3 | 1000D/3*3 | 1000D/2*5 | 1000D/5*3 | 1000D/4*3 | 1000D/6*3 | 1000D/6*5 | |
| Breaking Strength | N | ≥210 | ≥440 | ≥650 | ≥720 | ≥1050 | ≥860 | ≥1250 | ≥2100 |
| Elongation at Break | % | 9.5±1.5 | 9.5±1.5 | 9.5±1.5 | 9.5±1.5 | 9.5±1.5 | 9.5±1.5 | 9.5±1.5 | 10.0±2.0 |
| Elongation at Setload | % | 3.3±0.5 | 3.1±0.5 | 2.0±0.5 | 1.9±0.5 | 2.0±0.5 | 2.3±0.5 | 2.2±0.5 | 1.8±0.5 |
| @100N | @200N | @200N | @300N | @300N | @300N | @400N | @500N | ||
| Weight per 100 m | g/100m | 38±3 | 73±4 | 110±4 | 123±5 | 185±6 | 146±5 | 222±7 | 365±10 |
| Cord Diameter | mm | 0.68±0.1 | 0.95±0.1 | 1.15±0.1 | 1.25±0.1 | 1.5±0.1 | 1.65±0.1 | 1.95±0.15 | 2.1±0.15 |
| Hot air Shrinkage 150℃ 3min 130g | % | ≤3 | ≤3 | ≤3 | ≤2.8 | ≤2.8 | ≤2.6 | ≤2.8 | ≤2.8 |
| T-Adhesion at150℃30min | N/cm | ≥240 | ≥260 | ≥280 | ≥300 | ≥320 | ≥350 | ≥400 | ≥420 |
FAQ
1. Are you trading company or manufacturer ?
We are factory.
2. Can we get your free samples?
Sure, small sample is free of charge .But the freight for express is borne by buyer.
3.What Is your shipping term?
By sea/air/express.
4. How long is your dellvery time?
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
