China High Quality Dipped Nylon Soft Cord for V-belt
Non-slip mat is made of rubber textile composites to prevent injuries in floor areas, this can help to insure a long lifespan and low maintenance.
| Quantity: | |
|---|---|
-
kindom
| Dipped nylon 6 multifilament chafer | |||||
| SPEC | UNIT | 840D/1*840D/1 | 840D/1*840D/1 | 1260D/1*1260D/1 | 1260D/1*1260D/1 |
| content | Nylon6 | Nylon66 | Nylon6 | Nylon66 | |
| Weft Breaking strength | N/end | ≥69 | ≥71 | ≥103 | ≥105 |
| Warp Breaking strength | N/end | ≥67 | ≥68 | ≥100 | ≥102 |
| Weft Elongation at break | % | 30±5 | 30±5 | 30±5 | 30±5 |
| Warp Elongation at break | % | 25±5 | 25±5 | 25±5 | 25±5 |
| weft density | End/inch | Based on customers’request | Based on customers’request | Based on customers’request | Based on customers’request |
| warp density | End/inch | Based on customers’request | Based on customers’request | Based on customers’request | Based on customers’request |
| Weft shrinkage in hot air | % | ≤2.0 | ≤2.0 | ≤2.0 | ≤2.0 |
| Warp shrinkage in hot air | % | ≤3.0 | ≤3.0 | ≤3.0 | ≤3.0 |
| Adhesion | Kg/inch | ≥20 | ≥20 | ≥20 | ≥20 |
| Dip pick up | % | 11±3 | 11±3 | 11±3 | 11±3 |
| Water content | % | 1.5 | 1.5 | 1.5 | 1.5 |
| Thickness | mm | 0.52±0.07 | 0.52±0.07 | 0.65±0.07 | 0.65±0.07 |
| Width | cm | 100-150 | 100-150 | 100-150 | 100-150 |
| Dipped nylon 6 multifilament chafer | |||||
| SPEC | UNIT | 840D/1*840D/1 | 840D/1*840D/1 | 1260D/1*1260D/1 | 1260D/1*1260D/1 |
| content | Nylon6 | Nylon66 | Nylon6 | Nylon66 | |
| Weft Breaking strength | N/end | ≥69 | ≥71 | ≥103 | ≥105 |
| Warp Breaking strength | N/end | ≥67 | ≥68 | ≥100 | ≥102 |
| Weft Elongation at break | % | 30±5 | 30±5 | 30±5 | 30±5 |
| Warp Elongation at break | % | 25±5 | 25±5 | 25±5 | 25±5 |
| weft density | End/inch | Based on customers’request | Based on customers’request | Based on customers’request | Based on customers’request |
| warp density | End/inch | Based on customers’request | Based on customers’request | Based on customers’request | Based on customers’request |
| Weft shrinkage in hot air | % | ≤2.0 | ≤2.0 | ≤2.0 | ≤2.0 |
| Warp shrinkage in hot air | % | ≤3.0 | ≤3.0 | ≤3.0 | ≤3.0 |
| Adhesion | Kg/inch | ≥20 | ≥20 | ≥20 | ≥20 |
| Dip pick up | % | 11±3 | 11±3 | 11±3 | 11±3 |
| Water content | % | 1.5 | 1.5 | 1.5 | 1.5 |
| Thickness | mm | 0.52±0.07 | 0.52±0.07 | 0.65±0.07 | 0.65±0.07 |
| Width | cm | 100-150 | 100-150 | 100-150 | 100-150 |
